Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank 3102101130

3102101130

3102101130 3102101130

3102101130

Yamawa
Артикул: 3102101130
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL01402105
DRVS Drive size
11 mm
FamilyProducts
VUPO 374 ISO2X M18X1.5 coated tap
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
3102101130
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0140
LOC-03 DCONMS Diameter
14 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01402105
LS Shank length
56 mm
Materials
P,M,K,N,H
NOF Flute count
3
OAL Overall length
110 mm
OVERHANG LENGTH Overhang length
59.6 mm
PLCD Gate diameter
16.3 mm
PLG Plug style
B - Kappa r 8°
STDNO Standard
DIN374
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
7.5 mm
TCTR Thread tolerance class
ISO2X
TD Thread diameter
18 mm
THFT Thread form type
MF
THL Thread cutting part length
24 mm
THOD Thread designation
MF18x1.5-ISO2X
TP Thread pitch
1.5 mm
TTPID Tap type identifier
1 - Machine tap
Working process
BGD - Thread cutting, through hole
WT Weight of item
0.134 kg
