Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank 1215101100

1215101100

1215101100 1215101100

1215101100

Yamawa
Артикул: 1215101100
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
Delivery state valid from
10/1/2024
DIN
ZYL01052115
DRVS Drive size
8 mm
FamilyProducts
CAST CH P4 M14X2 1.5P coated tap
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
1215101100
Interface codes
J6 / J61
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LCF Length chip flute
51 mm
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
1 Metric with coolant
LOC-03 CZCMS Size code
0105
LOC-03 DCONMS Diameter
10.5 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01052115
LS Shank length
56 mm
Materials
K,N,H,O
NOF Flute count
4
OAL Overall length
110 mm
OVERHANG LENGTH Overhang length
59.6 mm
PLCD Gate diameter
12.1 mm
PLG Plug style
E - Kappa r 23°
STDNO Standard
JIS
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
3 mm
TCTR Thread tolerance class
P4
TD Thread diameter
14 mm
THFT Thread form type
M
THL Thread cutting part length
26 mm
THOD Thread designation
M14×2-P4
TP Thread pitch
2 mm
TTPID Tap type identifier
2 - Hand tap
Working process
BG - Tapping
WT Weight of item
0.083 kg
