Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank 1103101088

1103101088

1103101088 1103101088

1103101088

Yamawa
Артикул: 1103101088
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL00852105
DRVS Drive size
6.5 mm
FamilyProducts
VUSP 1.5P P4 M12X1.75 coated tap
FHA Flute helix angle
45 Degree
FHH Flute helix hand
R - Hand of helix right
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
1103101088
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0085
LOC-03 DCONMS Diameter
8.5 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00852105
LS Shank length
56 mm
Materials
P,M,K,N,H
NOF Flute count
3
OAL Overall length
110 mm
OVERHANG LENGTH Overhang length
59.6 mm
PLCD Gate diameter
10 mm
PLG Plug style
E - Kappa r 23°
STDNO Standard
JIS
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
2.625 mm
TCTR Thread tolerance class
P4
TD Thread diameter
12 mm
THFT Thread form type
M
THL Thread cutting part length
15 mm
THOD Thread designation
M12x1.75-P4
TP Thread pitch
1.75 mm
TTPID Tap type identifier
1 - Machine tap
Working process
BGS - Thread cutting, blind hole
WT Weight of item
0.055 kg
