Главная Каталог продукции Toolunited 13 301-01 - Thread cutting tap with offset shank 1101301116

1101301116

1101301116 1101301116

1101301116

Yamawa
Артикул: 1101301116
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
YMW - Yamawa
CXSC Coolant exit style code
0 - Without coolant exit
Delivery state valid from
6/1/2024
DIN
ZYL01252105
DRVS Drive size
10 mm
FamilyProducts
VUSP P5 M16X1.5 +40 coated tap
FHA Flute helix angle
48 Degree
FHH Flute helix hand
R - Hand of helix right
GRDPRIO Standard designation of the grade main application
HSS-P
HAND Cutting direction
R - Right
ID Identifying order number
1101301116
Interface codes
J6 /
ISYC Subclass
301-01 - Thread cutting tap with offset shank
LOC-03 CCFMS Form
21
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0125
LOC-03 DCONMS Diameter
12.5 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01252105
LS Shank length
56 mm
Materials
P,M,K,N,H
NOF Flute count
3
OAL Overall length
110 mm
OVERHANG LENGTH Overhang length
59.6 mm
PLCD Gate diameter
14.3 mm
PLG Plug style
C - Kappa r 15°
STDNO Standard
JIS
TCDCONMS ISO-tolerance class shank diameter
h8
TCL Tap chamfer length
3.75 mm
TCTR Thread tolerance class
P5
TD Thread diameter
16 mm
THFT Thread form type
MF
THL Thread cutting part length
14 mm
THOD Thread designation
MF16x1.5-P5
TP Thread pitch
1.5 mm
TTPID Tap type identifier
1 - Machine tap
Working process
BGS - Thread cutting, blind hole
WT Weight of item
0.108 kg
