Главная Каталог продукции Toolunited 13 306-04 - Face countersinking tool KPL090R2SS12N1M

KPL090R2SS12N1M

KPL090R2SS12N1M KPL090R2SS12N1M KPL090R2SS12N1M KPL090R2SS12N1M

KPL090R2SS12N1M

Kennametal
Артикул: 1804138
В наличии
В корзину
Описание
Характеристики
BI Block index
1
CCONMS Connection count machine side
1
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter minimum
8.8 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter 1st step maximum
9.2 mm
Delivery state valid from
1
DIN
ZYL01200115
FamilyProducts
KENDEX PRECISION BORE
FDC Flute design code
1 - Straight
GPP Guide pilot
0 - Without pilot
HAND Cutting direction
R - Right
ID Technical product number
1804138
Interface codes
J6 /
ISYC Subclass
306-04 - Face countersinking tool
LOC-01 BI Block index
1
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-01-DIN
KH-BPGX0301
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0120
LOC-03 DCONMS Diameter
12 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01200115
LPR Protruding length
30 mm
LU Usable length
70 mm
Name Identifying order number
KPL090R2SS12N1M
OAL Overall length
5 mm
SIG Point angle 1st step
180 Degree
Working process
No working processes available
