Главная Каталог продукции Toolunited 13 306-04 - Face countersinking tool KPL070R2SS12N1M

KPL070R2SS12N1M

KPL070R2SS12N1M KPL070R2SS12N1M KPL070R2SS12N1M KPL070R2SS12N1M

KPL070R2SS12N1M

Kennametal
Артикул: 1804136
В наличии
В корзину
Описание
Характеристики
BI Block index
1
CCONMS Connection count machine side
1
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter minimum
6.8 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter 1st step maximum
7.2 mm
Delivery state valid from
1
DIN
ZYL01200115
FamilyProducts
KENDEX PRECISION BORE
FDC Flute design code
1 - Straight
GPP Guide pilot
0 - Without pilot
HAND Cutting direction
R - Right
ID Technical product number
1804136
Interface codes
J6 /
ISYC Subclass
306-04 - Face countersinking tool
LOC-01 BI Block index
1
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-01-DIN
KH-BPGX0301
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0120
LOC-03 DCONMS Diameter
12 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01200115
LPR Protruding length
25 mm
LU Usable length
15 mm
Name Identifying order number
KPL070R2SS12N1M
OAL Overall length
70 mm
SIG Point angle 1st step
180 Degree
Working process
No working processes available
