Главная Каталог продукции Toolunited 13 306-04 - Face countersinking tool 216660 M5N

216660 M5N

Артикул: 216660 M5N

В наличии

В корзину

Описание

Характеристики

A1B Cutting edge angle major Pos. B

80 Degree

BD Body diameter 1st step

9 mm

BI Block index

BLDB Tool style code Position B

CCONMS Connection count machine side

CEDC Cutting edge count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

HOG - Hoffmann Group

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

10 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/11/2017

DIN

ZYL01601005

FamilyProducts

KOMET Countersinking mill

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

306-04 - Face countersinking tool

LOC-01 BI Block index

LOC-01 MIID Master insert identification

WOEX0402**

LOC-01-Connection-codes

J44 / J441 - Insert (Unknown 01)

LOC-01-DIN

WO0403 3N

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01601005

LPR Protruding length

24 mm

MIID Master insert identification

WOEX0402**

Name Identifying order number

216660 M5N

NUMBER INSERTS OUTSIDE Number of inserts outside

OAL Overall length

80 mm

PHD Premachined hole diameter

5.3 mm

SIG Point angle 1st step

180 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available

WT Weight of item

0.09 kg
