140350 M8
140350 M8
Артикул:
140350 M8
В наличии
Характеристики
BD Body diameter
25 mm
COMPC Company code
HOG - Hoffmann Group
DCP Data chip provision
0 - Without data chip
Delivery state valid from
6/1/2016
DIN
SEH02500105
FamilyProducts
HOLEX Schneideisen
GRDMFG Grade manufacturers designation
HSS
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-05 - Thread cutting die, round shape
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SEH die stock connection
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0250
LOC-03 DCONMS Diameter
25 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SEH02500105
Name Identifying order number
140350 M8
NOF Flute count
5
OAL Overall length
9 mm
STDNO Standard
DIN13
TCTR Thread tolerance class
6e
TD Thread diameter
8 mm
THFT Thread form type
M
THOD Thread designation
M8x1.25-6e
TP Thread pitch
1.25 mm
Working process
No working processes available
