140300 M5
140300 M5
Артикул:
140300 M5
В наличии
Характеристики
BD Body diameter
20 mm
COMPC Company code
HOG - Hoffmann Group
DCP Data chip provision
0 - Without data chip
Delivery state valid from
6/1/2016
DIN
SEH02000105
FamilyProducts
GARANT Schneideisen
GRDMFG Grade manufacturers designation
HSS
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
301-05 - Thread cutting die, round shape
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SEH die stock connection
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SEH02000105
Name Identifying order number
140300 M5
NOF Flute count
5
OAL Overall length
7 mm
STDNO Standard
DIN13
TCTR Thread tolerance class
6g
TD Thread diameter
5 mm
THFT Thread form type
M
THOD Thread designation
M5x0.8-6g
TP Thread pitch
0.8 mm
Working process
No working processes available
