Главная Каталог продукции Toolunited 12 309-00 - Tool holder for indexable inserts unspecified N050F-QC12

N050F-QC12

Артикул: 03280753

В наличии

В корзину

Описание

Характеристики

BI Block index

CEDC Cutting edge count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

SO - SECO Tools

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

Delivery state valid from

3/22/2022

DIN

VKT08120105

DIN CSW1

SO-SQC01G $$

FamilyProducts

N050F-QC12

HF Functional height

6.7 mm

ID Technical product number

03280753

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-00 - Tool holder for indexable inserts unspecified

LF Functional length

80 mm

LOC-01 BI Block index

LOC-01-Connection-codes

J41 / J441 - Interface code position A (cutting edge) (Unknown 01)

LOC-01-DIN

SO-SQC01G $$

LOC-02 BI Block index

LOC-02-Connection-codes

J41 / J441 - Interface code position A (cutting edge) (Unknown 02)

LOC-02-DIN

SO-SQC01G1200$$$$

LOC-03 B Shank width

12.35 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

VKT Square mounting

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0812

LOC-03 H Shank height

12.7 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

VKT08120105

LTA Length tool assembly

80 mm

Name Identifying order number

N050F-QC12

SX Shank cross section shape code

02 - Square shank

THSC Tool holder shape code

A - offset shank design

WF Functional width

6 mm

Working process

No working processes available

WT Weight of item

0.092 kg
