Главная Каталог продукции Toolunited 12 405-08 - Cylindrical clamping sleeve 05FHC200562

05FHC200562

05FHC200562 05FHC200562 05FHC200562

05FHC200562

SECO Tools
Артикул: 10137394
В наличии
В корзину
Описание
Характеристики
BD Body diameter
24 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
0
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0563
DCB Connection bore diameter
14.288 mm
Delivery state valid from
12/1/2023
DIN
SZC02000505
FamilyProducts
05FHC200562
ID Technical product number
10137394
Interface codes
J6 /
ISYC Subclass
405-08 - Cylindrical clamping sleeve
LCOL Collet length
50.5 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0563
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL05630105
LOC-03 CCFMS Connection code form
05
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SZC Collet adapter SANDVIK Coromant
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SZC02000505
LSC Clamping length
35.4 mm
LSCX Clamping length maximum
35.4 mm
Name Identifying order number
05FHC200562
WT Weight of item
0.057 kg
