P290 ACK D32-3-36-C5-18

Артикул: 3107184

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

36 mm

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter

32 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/1/2022

DIN

CCS05000295

FamilyProducts

Extended Flute Endmills with CAMFIX Shanks Carrying 18 mm Long Edged Inserts

HAND Cutting direction

R - Right

ID Technical product number

3107184

Interface codes

J6 / J61

ISO

CCS02C0500$$$$

ISYC Subclass

307-07 - Non-centre cutting multiple rows end mill

KAPR Tool cutting edge angle

90 Degree

LF Functional length

90 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

CCS Coromant Capto System SANDVIK

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0500

LOC-03 DCONMS Diameter

50 mm

LOC-03 ISO

CCS02C0500$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

CCS05000295

LPR Protruding length

90 mm

LU Usable length

64 mm

Name Identifying order number

P290 ACK D32-3-36-C5-18

OAL Overall length

90 mm

RMPX Ramping angle maximum

2 Degree

Working process

No working processes available

WT Weight of item

0.79 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
