Главная Каталог продукции Toolunited 12 307-04 - T-slot end mill TGSF 50-3-M12 5Z-JHP

TGSF 50-3-M12 5Z-JHP

Артикул: 3345227

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

2 - With Coolant exit, radial

DC Cutting diameter

50 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/1/2022

DIN

SAI01500295

FamilyProducts

Grooving and Slitting Small Diameter Cutters with FLEXFIT Threaded Adaptation

HAND Cutting direction

R - Right

ID Technical product number

3345227

Interface codes

J6 / J61

ISO

SAI02C0150$$$$

ISYC Subclass

307-04 - T-slot end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SAI Screw mounting ISCAR

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0150

LOC-03 ISO

SAI02C0150$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SAI01500295

MILTTY Mill tool type ISO

F - T-slot end mills

Name Identifying order number

TGSF 50-3-M12 5Z-JHP

OAL Overall length

24.7 mm

THSZMS Connection thread nominal size machine side

M12

Working process

No working processes available

WT Weight of item

0.06 kg
