Главная Каталог продукции Toolunited 12 201-00 - Regular Insert unspecified 5115502002

5115502002

Артикул: 5115502002

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

BS Wiper edge length

1.4 mm

CBMD Chip breaker manufacturers designation

-F10

CECC Cutting edge condition code

F - Sharpedged

COATN Coating

CTPX715

COMPC Company code

CE - Ceratizit

D1 Fixing hole diameter

2.8 mm

Delivery state valid from

10/1/2022

FamilyProducts

HM-FRÄSWENDEPLATTE

GRD2ND Standard designation of the grade 2nd application

HC-M15

GRD3RD Standard designation of the grade 3rd application

HC-N10

GRDPRIO Standard designation of the grade main application

HC-P15

IC Inscribed circle diameter

6.8 mm

IH Insert hand

R - Right

Interface codes

ISISO ISO property

ISYC Subclass

201-00 - Regular Insert unspecified

L Cutting edge length

10.6 mm

Name Identifying order number

5115502002

RE Corner radius

2 mm

S Insert thickness

3.8 mm

TCINS Tolerance class insert

Working process

No working processes available
