ONHU 070610-TR IC810
ONHU 070610-TR IC810
Артикул:
5668873
В наличии
Характеристики
BS Wiper edge length
1.5 mm
CECC Cutting edge condition code
T - Chamfered
COATN Coating / Покрытие
AlTiCrN+TiN
COMPC Company code
IS - Iscar
Delivery state valid from
4/1/2022
DIN
IS-319689948394410
FamilyProducts
Double-Sided Octagonal Inserts with 16 Cutting Edges
GRDMFG Grade manufacturers designation
IC810
IC Inscribed circle diameter
18.8 mm
ID Technical product number
5668873
IFS Insert mounting style code
4 - Counter bore for screws with taper angle from 70° to 90°
Interface codes
J6 / J441
ISISO ISO property
0
ISO
IS$$319689948394410
ISYC Subclass
201-09 - Octogonal insert
L Cutting edge length
7 mm
LOC-03 ISO
IS$$319689948394410
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
IS-319689948394410
Name Identifying order number
ONHU 070610-TR IC810
RE Corner radius
1 mm
S Insert thickness
6.5 mm
Working process
No working processes available
WT Weight of item
0.02 kg
