Главная Каталог продукции Toolunited 12 202-03 - Insert, two cutting edges for grooving and parting, self clamping GMM8030-080MW PR905

GMM8030-080MW PR905

Артикул: TJF12855

В наличии

В корзину

Описание

Характеристики

ANL Clearance angle flank left hand

5 Degree

ANR Clearance angle flank right hand

5 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

E - Rounded

COATN Coating / Покрытие

TiAlN

COMPC Company code

KYO - Kyocera

CW Cutting width

8 mm

Delivery state valid from

5/13/2022

DIN

KYO-GMM80-080

EPSR Insert included angle

90 Degree

FamilyProducts

KYOCERA GROOVING Insert GMM

GAN Insert rake angle

0 Degree

GRDMFG Grade manufacturers designation

PR905

GRDPRIO Standard designation of the grade main application

ID Technical product number

TJF12855

IFS Insert mounting style code

7 - Prismatic clamping, concave

IH Insert hand

N - Neutral

INSL Insert length

30 mm

Interface codes

J6 /

ISYC Subclass

202-03 - Insert, two cutting edges for grooving and parting, self clamping

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KYO-GMM80-080

Name Identifying order number

GMM8030-080MW PR905

NOF Flute count

PDPT Profile depth insert

30 mm

PFS Profile form

REL Corner radius left hand

0.8 mm

RER Corner radius right hand

0.8 mm

S Insert thickness

5.5 mm

S1 Insert thickness total

7.4 mm

TCE Tipped cutting edge code

W1 Insert width

6 mm

Working process

DSS - Face grooving,EEA - Grooving and cutting off

Главный задний угол (AN) / Clearance angle major (AN)

8.5 Degree
