Главная Каталог продукции Toolunited 12 311-01 - Solid cylindrical reamer 737 11.500

737 11.500

Артикул: 9007370115000

В наличии

В корзину

Описание

Характеристики

ADJBY Adjustment property

0 - Adjustment not possible

APMX Depth of cut maximum

28 mm

BMC Body material code

B - Steel body with brazed carbide inserts

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

OHNE

COMPC Company code

GG - Gühring

CPDF Cutting pitch differential

2 - Extreme unequal (e.g. 45-60-75 degree)

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

11.5 mm

DCONMSLD Shank diameter lower limit

-0.022 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL01000105

FamilyProducts

HM MASCH,-REIBAHLEN 11,500 DIN8090-C RN

FHA Flute helix angle

3 Degree

FHH Flute helix hand

R - Hand of helix right

GRD2ND Standard designation of the grade 2nd application

HM-BEST,

GRDMFG Grade manufacturers designation

34CRAN7

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

ID Technical product number

9007370115000

Interface codes

J6 /

ISYC Subclass

311-01 - Solid cylindrical reamer

LF Functional length

79.1 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0100

LOC-03 DCONMS Diameter

10 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01000105

LPR Protruding length

47 mm

LS Shank length

50.8 mm

LU Usable length

29.2 mm

Name Identifying order number

737 11.500

NOF Flute count

OAL Overall length

80 mm

PLANG Plug angle

PLGL Plug length

0.9 mm

RESYC Reaming tool style code

0 - For through-holes and blind holes

STDLET Standard letter to the standard number

STDNO Standard

DIN8090~

TCDH ISO tolerance class for drilling result

Working process

REI - Cylindrical reaming

WT Weight of item

0.051 kg
