Главная Каталог продукции Toolunited 12 311-01 - Solid cylindrical reamer 1407 10.000

1407 10.000

1407 10.000 1407 10.000

1407 10.000

Gühring
Артикул: 9014070100000
В наличии
В корзину
Описание
Характеристики
ADJBY Adjustment property
0 - Adjustment not possible
APMX Depth of cut maximum
25 mm
BMC Body material code
B - Steel body with brazed carbide inserts
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
OHNE
COMPC Company code
GG - Gühring
CPDF Cutting pitch differential
2 - Extreme unequal (e.g. 45-60-75 degree)
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter minimum
10 mm
DCONMSLD Shank diameter lower limit
-0.022 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL00800105
FamilyProducts
HM MASCH,-REIBA.EU 10,000 DIN8090-B RN
FHA Flute helix angle
7 Degree
FHH Flute helix hand
L - Hand of helix left
GRD2ND Standard designation of the grade 2nd application
HM-BEST,
GRDMFG Grade manufacturers designation
HM-BEST,
GRDPRIO Standard designation of the grade main application
HW
HAND Cutting direction
R - Right
ID Technical product number
9014070100000
Interface codes
J6 /
ISYC Subclass
311-01 - Solid cylindrical reamer
LF Functional length
70.1 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0080
LOC-03 DCONMS Diameter
8 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00800105
LPR Protruding length
52.5 mm
LU Usable length
71 mm
Name Identifying order number
1407 10.000
NOF Flute count
6
OAL Overall length
71 mm
PLANG Plug angle
45
PLGL Plug length
0.9 mm
RESYC Reaming tool style code
2 - For though-holes
STDLET Standard letter to the standard number
B
STDNO Standard
DIN8090~
TCDH ISO tolerance class for drilling result
H7
Working process
REI - Cylindrical reaming
WT Weight of item
0.032 kg
