1036 15.000
1036 15.000
Артикул:
9010360150000
В наличии
Характеристики
ADJBY Adjustment property
0 - Adjustment not possible
APMX Depth of cut maximum
22 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COATN Coating
SIGNUM-BESCHICHTET
COMPC Company code
GG - Gühring
CPDF Cutting pitch differential
2 - Extreme unequal (e.g. 45-60-75 degree)
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DC Cutting diameter minimum
15 mm
DCONMSLD Shank diameter lower limit
-0.011 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL01600115
FamilyProducts
VHM HR500 REI,KZ EU SIGNUM F.SL GG
FHH Flute helix hand
N - Hand of helix neutral
GRD2ND Standard designation of the grade 2nd application
VHM
GRDMFG Grade manufacturers designation
VHM
GRDPRIO Standard designation of the grade main application
HC-K/P
HAND Cutting direction
R - Right
ID Technical product number
9010360150000
Interface codes
J6 /
ISYC Subclass
311-01 - Solid cylindrical reamer
LF Functional length
149.4 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0160
LOC-03 DCONMS Diameter
16 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01600115
LPR Protruding length
102 mm
LS Shank length
48 mm
LU Usable length
102 mm
Name Identifying order number
1036 15.000
NOF Flute count
8
OAL Overall length
150 mm
PLANG Plug angle
60
PLGL Plug length
0.7 mm
RESYC Reaming tool style code
1 - For blind hole
STDNO Standard
WN 1036
TCDCONMS ISO-tolerance class shank diameter
h6
TCDH ISO tolerance class for drilling result
H7
Working process
REI - Cylindrical reaming
WT Weight of item
0.311 kg
