Главная Каталог продукции Toolunited 12 401-01 - Converter, rotationally symmetric E341456002585P

E341456002585P

E341456002585P E341456002585P E341456002585P E341456002585P

E341456002585P

Seco
Артикул: 02904887
В наличии
В корзину
Описание
Характеристики
BD Body diameter
59.13 mm
BD Body diameter 2
59.13 mm
BLQ Balance quality code
1
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
0
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
0250
DCINTF Interference cutting diameter
50 mm
DCONWS Diameter
25 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
6/7/2017
DIN
SKG04005085
FamilyProducts
E341456002585P
HAND Cutting direction
N - Neutral
ID Technical product number
02904887
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
58 mm
LF Functional length
36 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0250
LOC-01 DCONWS Diameter
25 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL02500105
LOC-03 CCFMS Connection code form
50
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04005085
LPR Protruding length
85 mm
LSCX Clamping length maximum
47 mm
Name Identifying order number
E341456002585P
OAL Overall length
150.4 mm
TA Taper angle
4.5 Degree
THSZWS Connection thread nominal size workpiece side
M16x1
WT Weight of item
1.8 kg
