Главная Каталог продукции Toolunited 12 303-11 - Thread end mill with drilling part 48348101

48348101

48348101

OSG

Артикул: 48348101

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

4.5 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COATN Coating / Покрытие

Multi-SiC layer

COMPC Company code

OSG

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCD Drilling diameter

9.8 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

9.8 mm

Delivery state valid from

2/1/2024

DIN

ZYL01000115

DN Neck diameter

7.74 mm

FamilyProducts

OSG WHO-EM-PNC D9,8 G1/4 x 19 LH

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

GAMF Rake angle radial

-10 Degree

GRDPRIO Standard designation of the grade main application

HC

HAND Cutting direction

L - Left

Interface codes

J6 /

ISYC Subclass

303-11 - Thread end mill with drilling part

LH Head length

4.5 mm

LN Neck length

30 mm

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0100

LOC-03 DCONMS Diameter

10 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01000115

LPR Protruding length

32 mm

LS Shank length

40.5 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

48348101

OAL Overall length

72 mm

PRFA Profile included angle

180 Degree

TCDCONMS ISO-tolerance class shank diameter

h6

TDFR Thread diameter nominal fraction

1/4 in

THFT Thread form type

G

TPI Threads per inch

19 1/in

Working process

No working processes available

ZEFF Face effective cutting edge count

4

ZEFP Peripheral effective cutting edge count

4
