MM TS225-H60A-06T06 IC908
MM TS225-H60A-06T06 IC908
Артикул:
3401424
В наличии
Характеристики
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
TiAlN
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
22.5 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/1/2022
DIN
SAI00600185
FamilyProducts
Interchangeable Solid Carbide T-Slot Milling Heads with Various Corner Radii
FHH Flute helix hand
R - Hand of helix right
GRDMFG Grade manufacturers designation
IC908
HAND Cutting direction
R - Right
ID Technical product number
3401424
Interface codes
J6 / J61
ISO
SAI01C0060$$$$
ISYC Subclass
303-05 - T-slot end mill
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SAI Screw mounting ISCAR
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0060
LOC-03 ISO
SAI01C0060$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SAI00600185
LPR Protruding length
6.5 mm
LS Shank length
6.7 mm
Name Identifying order number
MM TS225-H60A-06T06 IC908
OAL Overall length
13.25 mm
RE Corner radius
0.2 mm
Working process
No working processes available
WT Weight of item
0.02 kg
ZEFP Peripheral effective cutting edge count
6
