Главная Каталог продукции Toolunited 12 303-10 - Cutting stylus K205153-8

K205153-8

Артикул: K205153-8

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

6.928 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

AlphaDura Navy

COMPC Company code

HUV - Hofmann & Vratny

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

8 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/1/2023

DIN

ZYL00800105

FamilyProducts

Chamfmaker Z3-4 60° ADN

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-10 - Cutting stylus

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0080

LOC-03 DCONMS Diameter

8 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$05

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00800105

Materials

Name Identifying order number

K205153-8

OAL Overall length

59 mm

PRFA Profile included angle

60 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

FPR - Profile milling

ZEFF Face effective cutting edge count
