JHB970100D3B.0Z2 SIRA

JHB970100D3B.0Z2 SIRA JHB970100D3B.0Z2 SIRA JHB970100D3B.0Z2 SIRA JHB970100D3B.0Z2 SIRA

JHB970100D3B.0Z2 SIRA

Seco
Артикул: 10072079
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
15 mm
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
SIRON-A
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
10 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
ZYL01000105
FamilyProducts
JHB970100D3B.0Z2 SIRA
FHA Flute helix angle
30 Degree
FHH Flute helix hand
R - Hand of helix right
GAMF Rake angle radial
30 Degree
GAMP Rake angle axial
8 Degree
GRDMFG Grade manufacturers designation
SIRA
HAND Cutting direction
R - Right
ID Technical product number
10072079
Interface codes
J6 /
ISYC Subclass
303-06 - Ball-nosed end mill
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0100
LOC-03 DCONMS Diameter
10 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01000105
LS Shank length
40 mm
Name Identifying order number
JHB970100D3B.0Z2 SIRA
NameAnsi Identifying order number inch alternative
JHB970100D3B.0Z2
OAL Overall length
125 mm
PRFRAD Profile radius 1
4.985 mm
Working process
No working processes available
WT Weight of item
0.132 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
