19970 6.000
19970 6.000
Артикул:
9199700060000
В наличии
Характеристики
APMX Depth of cut maximum
30 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
FIRE
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
6 mm
DCONMSLD Shank diameter lower limit
-0.008 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL00600105
FamilyProducts
VHM FIRE POWERMILL VR-FRA WN-L RN 30° HA
FHA Flute helix angle
30 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
35.5 mm
GAMF Rake angle radial
30 Degree
GRD2ND Standard designation of the grade 2nd application
VHM
GRDMFG Grade manufacturers designation
VHM
GRDPRIO Standard designation of the grade main application
HC-K/P
HAND Cutting direction
R - Right
ID Technical product number
9199700060000
Interface codes
J6 /
ISYC Subclass
303-06 - Ball-nosed end mill
LF Functional length
75 mm
LN Neck length
39 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0060
LOC-03 DCONMS Diameter
6 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00600105
LPR Protruding length
39 mm
LS Shank length
36 mm
MILTTY Mill tool type ISO
L - Face and side end mill with ball nose (more then one indexable insert pro cutting edge) 90°
Name Identifying order number
19970 6.000
OAL Overall length
75 mm
PRFRAD Profile radius 1
3 mm
STDNO Standard
WN
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
FEC - Square shoulder milling
WT Weight of item
0.028 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
ZNC Cutting edge centre count
1
