Главная Каталог продукции Toolunited 12 303-09 - Thread end mill GF27310A.0050

GF27310A.0050

Артикул: GF27310A.0050

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

0.8 mm

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

AlCr-T42

COMPC Company code

E - Emuge

CXSC Coolant exit style code

0 - Without coolant exit

Delivery state valid from

10/1/2022

DIN

ZYL00601005

FamilyProducts

Zirkulargewindefräser / ZGF-MULTI

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

GRDMFG Grade manufacturers designation

VHM-AlCr-T

GRDPRIO Standard designation of the grade main application

VHM

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LF Functional length

38 mm

LH Head length

15.8 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00601005

LPR Protruding length

20 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

GF27310A.0050

OAL Overall length

56 mm

TD Thread diameter

5 mm

THFT Thread form type

TP Thread pitch

0.8 mm

Working process

FSC - Thread milling

WT Weight of item

0.014 kg

ZEFP Peripheral effective cutting edge count
