Главная Каталог продукции Toolunited 12 303-09 - Thread end mill 4002 3.500

4002 3.500

Артикул: 9040020035000

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

1.8 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

8 - With coolant supply (entry), axial groove at shank

COATN Coating / Покрытие

OHNE

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

7 - With coolant supply (discharge), axial groove at shank

DCONMSLD Shank diameter lower limit

-0.008 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

2.7 mm

Delivery state valid from

12/1/2021

DIN

ZYL00601015

DN Neck diameter

1.95 mm

FamilyProducts

VHM TISIN MICRO-GFR MTMH3-Z M 3,5

FHH Flute helix hand

N - Hand of helix neutral

GRD2ND Standard designation of the grade 2nd application

VHM

GRDMFG Grade manufacturers designation

VHM

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

L - Left

ID Technical product number

9040020035000

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LF Functional length

40 mm

LN Neck length

9 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00601015

LPR Protruding length

15 mm

LS Shank length

45.5 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

4002 3.500

OAL Overall length

58 mm

STDNO Standard

WN MTMH3-Z

TCDCONMS ISO-tolerance class shank diameter

TD Thread diameter

3.5 mm

THFT Thread form type

TP Thread pitch

0.6 mm

Working process

FSC - Thread milling

WT Weight of item

0.02 kg

ZEFP Peripheral effective cutting edge count
