MA230.12.7A9S038-WJ30TF
MA230.12.7A9S038-WJ30TF
Артикул:
8414882
В наличии
Характеристики
APMX Depth of cut maximum
31.75 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
TiAlN
COMPC Company code
W - Walter
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
12.7 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
ZYL05000125
F71 Number of corner designs
1
FamilyProducts
Solid carbide shoulder/slot mills MA230
FHA Flute helix angle
45 Degree
FHH Flute helix hand
R - Hand of helix right
GAMF Rake angle radial
12 Degree
GAMP Rake angle axial
12 Degree
GRDMFG Grade manufacturers designation
WJ30TF
HAND Cutting direction
R - Right
ID Technical product number
8414882
Interface codes
J6 / J61
ISO
ZYL01R5000h$06
ISYC Subclass
303-01 - Non-centre cutting end mill
LF Functional length
76.2 mm
LOC-03 CCFMS Form
01
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
2 Inch
LOC-03 CZCMS Size code
0500
LOC-03 DCONMS Diameter
12.7 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$06
LOC-03 ISO
ZYL01R5000h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL05000125
LPR Protruding length
38.2 mm
LS Shank length
38 mm
Materials
P,M,K,S
Name Identifying order number
MA230.12.7A9S038-WJ30TF
OAL Overall length
76.2 mm
RE Corner radius
0.381 mm
RMPX Ramping angle maximum
3 Degree
RPMX Rotational speed maximum
80000 1/min
STDNO Standard
P-NORM S
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
FEC - Square shoulder milling,FFO - Die milling,FPL - Face milling,FZI - Circular milling
WT Weight of item
0.122 kg
ZEFF Face effective cutting edge count
9
ZEFP Peripheral effective cutting edge count
9
