281 6.300
281 6.300
Артикул:
9002810063000
В наличии
Характеристики
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
1
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
OHNE
COMPC Company code
GG - Gühring
CRCLDIN Chip removal class
N
CTRSYC Centre drill style code
A - Form A
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter minimum
6.3 mm
DCONMSLD Shank diameter lower limit
-0.033 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL02000105
DRSYC Drill tool style code
6 - center drill
FamilyProducts
HSS ZENTRIERBOHRER WN FORM A 6,30
FHA Flute helix angle
29 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
112 mm
GRDMFG Grade manufacturers designation
HSS
GRDPRIO Standard designation of the grade main application
HSS
GRDSYC Grind style code
A
HAND Cutting direction
R - Right
ID Technical product number
9002810063000
Interface codes
J6 /
ISYC Subclass
302-07 - Centre drill
LCF Length chip flute
32 mm
LF Functional length
78.1 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$08
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02000105
LPR Protruding length
40 mm
LU Usable length
20.2 mm
Name Identifying order number
281 6.300
NOF Flute count
2
OAL Overall length
80 mm
PL Point length
1.9 mm
SDL Step diameter length
4.5 mm
SIG Point angle 1st step
118 Degree
STDLET Standard letter to the standard number
A
STDNO Standard
WN
TCDCONMS ISO-tolerance class shank diameter
h8
Working process
BZB - Center-drilling
WT Weight of item
0.101 kg
