Главная Каталог продукции Toolunited 12 302-02 - Step drill 514 7.400

514 7.400

514 7.400 514 7.400

514 7.400

Gühring
Артикул: 9005140074000
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
1
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
DAMPF ANGELASSEN
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter minimum
4.3 mm
DCONMSLD Shank diameter lower limit
-0.103 mm
DCONMSUD Shank diameter upper limit
-0.013 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL00740105
DRSYC Drill tool style code
2 - subland step drill
FamilyProducts
HSS MEHRFASENBOH, 7,4 x 4,3 WN 17RN ZYL
FHA Flute helix angle
27 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
42.5 mm
GRDMFG Grade manufacturers designation
HSS
GRDPRIO Standard designation of the grade main application
HSS
GRDSYC Grind style code
A
HAND Cutting direction
R - Right
ID Technical product number
9005140074000
Interface codes
J6 /
ISYC Subclass
302-02 - Step drill
LCF Length chip flute
69 mm
LF Functional length
107.7 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0074
LOC-03 DCONMS Diameter
7.4 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00740105
LPR Protruding length
74 mm
LS Shank length
40 mm
LU Usable length
58 mm
Name Identifying order number
514 7.400
NOF Flute count
2
NOS Step count
2
OAL Overall length
109 mm
PL Point length
1.3 mm
SDL Step diameter length
13 mm
SIG Point angle 1st step
118 Degree
STDNO Standard
WN 17
Working process
BPB - Drilling of profiles
WT Weight of item
0.023 kg
