Главная Каталог продукции Toolunited 12 302-02 - Step drill 380 11.000

380 11.000

Артикул: 9003800110000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

OHNE

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

8.5 mm

DCONMSLD Shank diameter lower limit

-0.011 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL01100105

FamilyProducts

HSS KURZSTUFENBOHRER 11,000 WN 16RN KERN

FHA Flute helix angle

29 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

63 mm

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSS

GRDSYC Grind style code

HAND Cutting direction

R - Right

ID Technical product number

9003800110000

Interface codes

J6 /

ISYC Subclass

302-02 - Step drill

LCF Length chip flute

47 mm

LF Functional length

92.4 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0110

LOC-03 DCONMS Diameter

11 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01100105

LPR Protruding length

52 mm

LS Shank length

48 mm

LU Usable length

33 mm

Name Identifying order number

380 11.000

NOF Flute count

NOS Step count

OAL Overall length

95 mm

PL Point length

2.6 mm

SDL Step diameter length

25.5 mm

SIG Point angle 1st step

118 Degree

STDNO Standard

WN 16

Working process

BPB - Drilling of profiles

WT Weight of item

0.05 kg
