1032 20.004
1032 20.004
Артикул:
9010320200040
В наличии
Характеристики
BMC Body material code
H - Solid carbide
CCONMS Connection count machine side
1
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
OHNE
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter minimum
16 mm
DCONMSLD Shank diameter lower limit
-0.013 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL02000105
FamilyProducts
VHM STUFENDREISCHN, D X 16,0 WN 33RN K10
FHA Flute helix angle
28 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
118 mm
GRD2ND Standard designation of the grade 2nd application
VHM
GRDMFG Grade manufacturers designation
VHM
GRDPRIO Standard designation of the grade main application
HF-K
GRDSYC Grind style code
GG-KG
HAND Cutting direction
R - Right
ID Technical product number
9010320200040
Interface codes
J6 /
ISYC Subclass
302-02 - Step drill
LCF Length chip flute
79 mm
LF Functional length
128.8 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02000105
LPR Protruding length
84 mm
LS Shank length
52 mm
LU Usable length
52 mm
Name Identifying order number
1032 20.004
NOF Flute count
3
NOS Step count
2
OAL Overall length
131 mm
PL Point length
2.2 mm
SDL Step diameter length
43 mm
SIG Point angle 1st step
150 Degree
STDNO Standard
WN 33
TCDCONMS ISO-tolerance class shank diameter
h6
THSZMS Connection thread nominal size machine side
M18 X2
Working process
BPB - Drilling of profiles
WT Weight of item
0.398 kg
