Главная Каталог продукции Toolunited 12 302-06 - Spot drill 1135 8.000

1135 8.000

Артикул: 9011350080000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

NANOFIRE

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

8 mm

DCONMSLD Shank diameter lower limit

-0.009 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL00801005

FamilyProducts

HSCO FIRE NC-ANBOHRER 120° ZYL WN RN

FHA Flute helix angle

21 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

63 mm

GRD2ND Standard designation of the grade 2nd application

HSCO

GRDMFG Grade manufacturers designation

HSCO

GRDPRIO Standard designation of the grade main application

HSS-E

HAND Cutting direction

R - Right

ID Technical product number

9011350080000

Interface codes

J6 / J61

ISO

ZYL10F8000h$06

ISYC Subclass

302-06 - Spot drill

LCF Length chip flute

21 mm

LF Functional length

58.6 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0080

LOC-03 DCONMS Diameter

8 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03 ISO

ZYL10F8000h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00801005

LPR Protruding length

43 mm

LS Shank length

36 mm

LU Usable length

16.8 mm

Name Identifying order number

1135 8.000

NOF Flute count

OAL Overall length

79 mm

PL Point length

2.4 mm

SIG Point angle 1st step

120 Degree

STDNO Standard

WN 10

TCDCONMS ISO-tolerance class shank diameter

Working process

BZB - Center-drilling

WT Weight of item

0.013 kg
