Главная Каталог продукции Toolunited 12 303-02 - Centre cutting end mill XSE550E20200D2R200Z4 SIRA

XSE550E20200D2R200Z4 SIRA

XSE550E20200D2R200Z4 SIRA XSE550E20200D2R200Z4 SIRA XSE550E20200D2R200Z4 SIRA XSE550E20200D2R200Z4 SIRA

XSE550E20200D2R200Z4 SIRA

SECO Tools
Артикул: 10138173
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
24 mm
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
SIRON-A
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
20 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
SMM02000305
F71 Number of corner designs
1
FamilyProducts
XSE550E20200D2R200Z4 SIRA
FHA Flute helix angle
48 Degree
FHH Flute helix hand
R - Hand of helix right
GAMF Rake angle radial
10 Degree
GAMP Rake angle axial
8 Degree
GRDMFG Grade manufacturers designation
SIRA
HAND Cutting direction
R - Right
ID Technical product number
10138173
Interface codes
J6 /
ISYC Subclass
303-02 - Centre cutting end mill
LF Functional length
34.3 mm
LH Head length
25 mm
LOC-03 CCFMS Connection code form
03
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SMM
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0200
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SMM02000305
Name Identifying order number
XSE550E20200D2R200Z4 SIRA
NameAnsi Identifying order number inch alternative
XSE550E20200D2R200Z4
RMPX Ramping angle maximum
5 Degree
Working process
No working processes available
WT Weight of item
0.148 kg
ZEFF Face effective cutting edge count
4
ZEFP Peripheral effective cutting edge count
4
