Главная Каталог продукции Toolunited 12 303-02 - Centre cutting end mill UMC-4E-D16.0 KMG405

UMC-4E-D16.0 KMG405

Артикул: UMC-4E-D16.0 KMG405

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

48 mm

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

AlCrN

COMPC Company code

ZCC - ZCC Cutting Tools

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

16 mm

DCP Data chip provision

0 - Without data chip

Delivery state

SF - Made to order

DIN

ZYL01600105

DN Neck diameter

15.5 mm

F71 Number of corner designs

FamilyProducts

End mill

FHA Flute helix angle

40 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

KMG405

HAND Cutting direction

R - Right

ID Identifying order number

UMC-4E-D16.0 KMG405

Interface codes

J6 /

ISYC Subclass

303-02 - Centre cutting end mill

LN Neck length

62 mm

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

ZYL cylindrical shank

LOC-03 CCUMS Unit base

0 Metric

LOC-03 CZCMS Size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03 TCDCONCDMS Tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01600105

MILTTY Mill tool type ISO

H - Slotting end mill (one or more indexable insert pro cutting edge) 90°

OAL Overall length

110 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

FEC - Square shoulder milling,FNU - Groove milling,FPL - Face milling,FSE - Counter-sinking,FZI - Circular milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
