Главная Каталог продукции Toolunited 12 303-02 - Centre cutting end mill MM10-10007-R04A8-E03 F30M

MM10-10007-R04A8-E03 F30M

MM10-10007-R04A8-E03 F30M MM10-10007-R04A8-E03 F30M MM10-10007-R04A8-E03 F30M MM10-10007-R04A8-E03 F30M

MM10-10007-R04A8-E03 F30M

Seco
Артикул: 00083497
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
6.6 mm
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
10 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
SMM01000105
F71 Number of corner designs
1
FamilyProducts
MM10-10007-R04A8-E03 F30M
FHA Flute helix angle
8 Degree
GAMF Rake angle radial
20 Degree
GAMP Rake angle axial
16 Degree
GRDMFG Grade manufacturers designation
F30M
ID Technical product number
00083497
Interface codes
J6 /
ISYC Subclass
303-02 - Centre cutting end mill
LF Functional length
8.44 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SMM
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0100
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SMM01000105
Name Identifying order number
MM10-10007-R04A8-E03 F30M
NameAnsi Identifying order number inch alternative
MM10-0.394-R1A8-E03
RMPX Ramping angle maximum
15 Degree
Working process
No working processes available
WT Weight of item
0.011 kg
ZEFF Face effective cutting edge count
1
ZEFP Peripheral effective cutting edge count
1
