Главная Каталог продукции Toolunited 12 303-02 - Centre cutting end mill 5493 4.000

5493 4.000

Артикул: 9054930040000

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

6 mm

BMC Body material code

B - Steel body with brazed carbide inserts

CNSC Coolant entry style code

4 - With Coolant entry, axial on hole circle

COATN Coating / Покрытие

OHNE

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

4 - With Coolant exit, axial on hole circle

DC Cutting diameter

4 mm

DCONMSLD Shank diameter lower limit

-0.008 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL00600115

DN Neck diameter

3.7 mm

F71 Number of corner designs

FamilyProducts

PKD BOHRNUTENFRÄSER KI 2S WN R ZYL

FHA Flute helix angle

2 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

355 mm

GAMF Rake angle radial

2 Degree

GRD2ND Standard designation of the grade 2nd application

PKD

GRDMFG Grade manufacturers designation

K30/K40

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

ID Technical product number

9054930040000

Interface codes

J6 /

ISYC Subclass

303-02 - Centre cutting end mill

LN Neck length

14 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00600115

LPR Protruding length

15 mm

LS Shank length

55 mm

MILTTY Mill tool type ISO

H - Slotting end mill (one or more indexable insert pro cutting edge) 90°

Name Identifying order number

5493 4.000

OAL Overall length

70 mm

RE Corner radius

0.1 mm

STDLET Standard letter to the standard number

STDNO Standard

TCDCONMS ISO-tolerance class shank diameter

Working process

FNB - Slotting

WT Weight of item

0.028 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
