3367 20.030
3367 20.030
Артикул:
9033670200300
В наличии
Характеристики
APMX Depth of cut maximum
32 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COATN Coating
OHNE
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DC Cutting diameter
20 mm
DCONMSLD Shank diameter lower limit
-0.013 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL02000115
DN Neck diameter
19.5 mm
F71 Number of corner designs
1
FamilyProducts
VHM FRA-BN 3S KI ECKRADIUS WN 45 ZYL HA
FHA Flute helix angle
45 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
63 mm
GAMF Rake angle radial
45 Degree
GRD2ND Standard designation of the grade 2nd application
VHM
GRDMFG Grade manufacturers designation
VHM
GRDPRIO Standard designation of the grade main application
HF-K
HAND Cutting direction
R - Right
ID Technical product number
9033670200300
Interface codes
J6 /
ISYC Subclass
303-02 - Centre cutting end mill
LF Functional length
104 mm
LN Neck length
52 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02000115
LPR Protruding length
54 mm
LS Shank length
50 mm
MILTTY Mill tool type ISO
H - Slotting end mill (one or more indexable insert pro cutting edge) 90°
Name Identifying order number
3367 20.030
OAL Overall length
104 mm
RE Corner radius
3 mm
STDNO Standard
WN
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
FNB - Slotting
WT Weight of item
0.39 kg
ZEFF Face effective cutting edge count
3
ZEFP Peripheral effective cutting edge count
3
ZNC Cutting edge centre count
1
