3168 25.400
3168 25.400
Артикул:
9031680254000
В наличии
Характеристики
APMX Depth of cut maximum
38 mm
BMC Body material code
H - Solid carbide
CHW Corner chamfer width
0.3 mm
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
OHNE
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
25.4 mm
DCONMSLD Shank diameter lower limit
-0.013 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL10000125
F71 Number of corner designs
1
FamilyProducts
VHM BLA,FRA-BN WN-USA 3S KU 25,400 1
FHA Flute helix angle
30 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
140 mm
GAMF Rake angle radial
30 Degree
GRD2ND Standard designation of the grade 2nd application
VHM
GRDMFG Grade manufacturers designation
VHM
GRDPRIO Standard designation of the grade main application
HF-K
HAND Cutting direction
R - Right
ID Technical product number
9031680254000
Interface codes
J6 /
ISYC Subclass
303-02 - Centre cutting end mill
KCH Corner chamfer angle
45 Degree
LN Neck length
59 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
1000
LOC-03 DCONMS Diameter
25.4 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL10000125
LPR Protruding length
64 mm
LS Shank length
42.6 mm
MILTTY Mill tool type ISO
H - Slotting end mill (one or more indexable insert pro cutting edge) 90°
Name Identifying order number
3168 25.400
OAL Overall length
101.6 mm
STDNO Standard
WN USA
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
FNB - Slotting
WT Weight of item
0.581 kg
ZEFF Face effective cutting edge count
3
ZEFP Peripheral effective cutting edge count
3
ZNC Cutting edge centre count
1
