3146 1.590
3146 1.590
Артикул:
9031460015900
В наличии
Характеристики
APMX Depth of cut maximum
4.8 mm
BMC Body material code
H - Solid carbide
CHW Corner chamfer width
0.025 mm
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
OHNE
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
1.59 mm
DCONMSLD Shank diameter lower limit
-0.008 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL01250125
F71 Number of corner designs
1
FamilyProducts
VHM BLA,FRA-BN WN-USA 2S KU 1,590 1/16
FHA Flute helix angle
30 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
9 mm
GAMF Rake angle radial
30 Degree
GRD2ND Standard designation of the grade 2nd application
VHM
GRDMFG Grade manufacturers designation
VHM
GRDPRIO Standard designation of the grade main application
HF-K
HAND Cutting direction
R - Right
ID Technical product number
9031460015900
Interface codes
J6 /
ISYC Subclass
303-02 - Centre cutting end mill
KCH Corner chamfer angle
45 Degree
LN Neck length
8.2 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
0125
LOC-03 DCONMS Diameter
3.175 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01250125
LPR Protruding length
9 mm
LS Shank length
28.8 mm
MILTTY Mill tool type ISO
H - Slotting end mill (one or more indexable insert pro cutting edge) 90°
Name Identifying order number
3146 1.590
OAL Overall length
38.1 mm
STDNO Standard
WN USA
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
FNB - Slotting
WT Weight of item
0.003 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
ZNC Cutting edge centre count
1
