19994 16.000
19994 16.000
Артикул:
9199940160000
В наличии
Характеристики
APMX Depth of cut maximum
16 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
OHNE
COMPC Company code
GG - Gühring
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
16 mm
DCONMSLD Shank diameter lower limit
-0.011 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2021
DIN
ZYL01600105
F71 Number of corner designs
1
FamilyProducts
VHM POWERMILL FRA 2S ALU WN RW KURZ HA
FHA Flute helix angle
35 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
71 mm
GAMF Rake angle radial
35 Degree
GRD2ND Standard designation of the grade 2nd application
VHM
GRDMFG Grade manufacturers designation
VHM
GRDPRIO Standard designation of the grade main application
HF-K
HAND Cutting direction
R - Right
ID Technical product number
9199940160000
Interface codes
J6 /
ISYC Subclass
303-02 - Centre cutting end mill
LF Functional length
82 mm
LN Neck length
34 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0160
LOC-03 DCONMS Diameter
16 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01600105
LPR Protruding length
34 mm
LS Shank length
48 mm
MILTTY Mill tool type ISO
H - Slotting end mill (one or more indexable insert pro cutting edge) 90°
Name Identifying order number
19994 16.000
OAL Overall length
82 mm
STDNO Standard
WN
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
FNB - Slotting
WT Weight of item
0.23 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
