Главная Каталог продукции Toolunited 12 308-02 - Shoulder milling cutter MFWN90063R-05-6T-M

MFWN90063R-05-6T-M

MFWN90063R-05-6T-M

MFWN90063R-05-6T-M

Kyocera
Артикул: THN08522
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
92 Degree
A2A Clearance angle major Pos. A
0 Degree
ADJBY Adjustment property
0 - Adjustment not possible
AZ Plunge depth maximum
3.9 mm
B3A Inscribed circle diameter Pos. A
8.8 mm
BD Body diameter
60 mm
BLDA Tool style code Position A
7
BLQ Balance quality code
0
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
4.2 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
5 mm
CICT Cutting item count
6
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D1A Corner radius Pos. A
0.8 mm
DC Cutting diameter
63 mm
DCCB Counterbore diameter connection bore
18 mm
Delivery state valid from
10/1/2022
DHUB Hub diameter
48 mm
DIN
FDA02202210
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
6
FamilyProducts
MFWN Mini Low cutting force 90°Milling cutter
GAMF Rake angle radial
-6 Degree
GAMP Rake angle axial
-8 Degree
HAND Cutting direction
R - Right
ID Technical product number
THN08522
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
308-02 - Shoulder milling cutter
KAPR Tool cutting edge angle
90 Degree
LCCB Counterbore depth connection bore
9 mm
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0220
LOC-03 DCONMS Diameter
22 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA02202210
MILTTY Mill tool type ISO
A - Face milling cutter shoulder cutter peripheral
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MFWN90063R-05-6T-M
OAL Overall length
40 mm
RMPX Ramping angle maximum
0 Degree
RPMX Rotational speed maximum
12300 1/min
THUB hub thickness
8.5 mm
Working process
No working processes available
WT Weight of item
0.5 kg
ZEFF Face effective cutting edge count
6
ZEFP Peripheral effective cutting edge count
6
