Главная Каталог продукции Toolunited 12 308-02 - Shoulder milling cutter MFLN90250R-10T

MFLN90250R-10T

MFLN90250R-10T

MFLN90250R-10T

Kyocera
Артикул: THN08441
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
0 Degree
ADJBY Adjustment property
0 - Adjustment not possible
AZ Plunge depth maximum
2.8 mm
B2A Insert width Pos. A
12.5 mm
BD Body diameter
244 mm
BLDA Tool style code Position A
99
BLQ Balance quality code
0
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
16.6 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
20 mm
CICT Cutting item count
10
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
0 - Without coolant exit
D1A Corner radius Pos. A
1.6 mm
DC Cutting diameter
250 mm
DCCB Counterbore diameter connection bore
172 mm
Delivery state valid from
10/1/2022
DHUB Hub diameter
142 mm
DIN
FDA18751220
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
10
FamilyProducts
MFLN for Heavy Milling
GAMF Rake angle radial
-13 Degree
GAMP Rake angle axial
-13 Degree
HAND Cutting direction
R - Right
ID Technical product number
THN08441
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
308-02 - Shoulder milling cutter
KAPR Tool cutting edge angle
90 Degree
LCCB Counterbore depth connection bore
20.2 mm
LOC-03 CCFMS Connection code form
12
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
1875
LOC-03 DCONMS Diameter
47.625 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA18751220
MILTTY Mill tool type ISO
A - Face milling cutter shoulder cutter peripheral
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MFLN90250R-10T
OAL Overall length
63 mm
RMPX Ramping angle maximum
0 Degree
RPMX Rotational speed maximum
1910 1/min
THUB hub thickness
14.5 mm
Working process
No working processes available
WT Weight of item
10.5 kg
ZEFF Face effective cutting edge count
10
ZEFP Peripheral effective cutting edge count
10
