Главная Каталог продукции Toolunited 12 308-02 - Shoulder milling cutter MFLN90125R-6T-M

MFLN90125R-6T-M

MFLN90125R-6T-M

MFLN90125R-6T-M

MFLN90125R-6T-M

Kyocera

Артикул: THN08445

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

0 Degree

ADJBY Adjustment property

0 - Adjustment not possible

AZ Plunge depth maximum

2.8 mm

B2A Insert width Pos. A

12.5 mm

BD Body diameter

119 mm

BLDA Tool style code Position A

99

BLQ Balance quality code

0

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

16.6 mm

CCONMS Connection count machine side

1

CDX Cutting depth maximum

20 mm

CICT Cutting item count

6

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

0 - Without coolant exit

D1A Corner radius Pos. A

1.6 mm

DC Cutting diameter

125 mm

DCCB Counterbore diameter connection bore

55 mm

Delivery state valid from

10/1/2022

DHUB Hub diameter

89 mm

DIN

FDA04001200

F23 Number of mounting layers

1

F24 Cutting item count per mounting layer

6

FamilyProducts

MFLN for Heavy Milling

GAMF Rake angle radial

-13.5 Degree

GAMP Rake angle axial

-13.5 Degree

HAND Cutting direction

R - Right

ID Technical product number

THN08445

Interface codes

J6 /

ISISO A Indicator for ISO cutting plate Pos.A

0

ISYC Subclass

308-02 - Shoulder milling cutter

KAPR Tool cutting edge angle

90 Degree

LCCB Counterbore depth connection bore

25.2 mm

LOC-03 CCFMS Connection code form

12

LOC-03 CCSMS Connection code style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Connection code type

FDA Milling arbor mounting

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0400

LOC-03 DCONMS Diameter

40 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA04001200

MILTTY Mill tool type ISO

A - Face milling cutter shoulder cutter peripheral

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

MFLN90125R-6T-M

OAL Overall length

63 mm

RMPX Ramping angle maximum

0 Degree

RPMX Rotational speed maximum

3820 1/min

THUB hub thickness

14.5 mm

Working process

No working processes available

WT Weight of item

2.9 kg

ZEFF Face effective cutting edge count

6

ZEFP Peripheral effective cutting edge count

6
