Главная Каталог продукции Toolunited 12 309-04 - Turning tool for OD grooving and parting KGDFL2525X220-4CS

KGDFL2525X220-4CS

KGDFL2525X220-4CS

KGDFL2525X220-4CS

Kyocera
Артикул: THT04349
В наличии
В корзину
Описание
Характеристики
A1A SKJ Cutting edge angle major Pos. A
1
A2A SKJ Stechbreite Nennmaß Schneidkörper Pos.A
4 mm
AXGSUP Axial groove support direction
2
BLDA SKJ Tool style code Position A
1
C5A SKJ Eckenradius rechts Schneidkörper Pos.A
0.4 mm
C6A SKJ Eckenradius links Schneidkörper Pos.A
0.4 mm
CDX Cutting depth maximum
25 mm
CEATC Tool cutting edge angle type code
E - Front lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KYO - Kyocera
CW Cutting width
4 mm
CXSC Coolant exit style code
0 - Without coolant exit
DAXN Axial groove od min
220 mm
DAXX Axial groove od max
9999.999 mm
DCC Design configuration style code
S - Solid steel, no construction features
DCP Data chip provision
0 - Without data chip
Delivery state valid from
5/13/2022
DHD Drop head design
2 - Normal and overhead
DIN
VKT25250105
FamilyProducts
KYOCERA FACE GROOVING TOOLHOLDER
G1A SKJ Schneidkörperlänge Schneidkörper Pos.A
20 mm
G7A SKJ Schneidkantenhöhe Schneidkörper Pos.A
3.6 mm
GAMF Rake angle radial
0 Degree
HAND Cutting direction
L - Left
HF Functional height
25 mm
ID Technical product number
THT04349
Interface codes
J6 /
ISYC Subclass
309-04 - Turning tool for OD grooving and parting
KAPR Tool cutting edge angle
90 Degree
LF Functional length
155 mm
LH Head length
48 mm
LOC-03 B Shank width
25 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
VKT Square mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
2525
LOC-03 H Shank height
25 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT25250105
Name Identifying order number
KGDFL2525X220-4CS
OAL Overall length
155 mm
SX Shank cross section shape code
01 - Square shank
THSC Tool holder shape code
A - offset shank design
WF Functional width
27.5 mm
Working process
DSS - Face grooving
