Главная Каталог продукции Toolunited 12 302-01 - Twist Drill TA403324.0565

TA403324.0565

Артикул: TA403324.0565

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating

TIALN-T14

COMPC Company code

E - Emuge

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

5.65 mm

DCONMSLD Shank diameter lower limit

-0.008 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

10/1/2022

DIN

ZYL00601305

DRSYC Drill tool style code

1 - subland twist drill

FamilyProducts

Twist drill

FHA Flute helix angle

30.198 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

30.5 mm

GRDMFG Grade manufacturers designation

K45F

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

28 mm

LF Functional length

64.971 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00601305

LPR Protruding length

30 mm

LS Shank length

36 mm

LU Usable length

20 mm

Name Identifying order number

TA403324.0565

NOF Flute count

OAL Overall length

66 mm

PL Point length

1.029 mm

SIG Point angle 1st step

140 Degree

STDLET Standard letter to the standard number

STDNO Standard

DIN 6537

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling

WT Weight of item

0.023 kg
