Главная Каталог продукции Toolunited 12 302-01 - Twist Drill 266 35.000

266 35.000

Артикул: 9002660350000

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

DAMPF ANGELASSEN

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

35 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

MKG00402085

FamilyProducts

HSS SPIRALBOHRER DIN 1870RN REIHE 1 MK

FHA Flute helix angle

35 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

170 mm

GRD2ND Standard designation of the grade 2nd application

HSS

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSS

GRDSYC Grind style code

HAND Cutting direction

R - Right

ID Technical product number

9002660350000

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

340 mm

LF Functional length

401.9 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

MKG Morse taper

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0040

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

MKG00402085

LPR Protruding length

412.5 mm

LS Shank length

124 mm

LU Usable length

304 mm

Name Identifying order number

266 35.000

NOF Flute count

OAL Overall length

530 mm

PL Point length

10.6 mm

SIG Point angle 1st step

118 Degree

STDNO Standard

DIN1870K

Working process

BVB - Drilling

WT Weight of item

2.502 kg
