Главная Каталог продукции Toolunited 12 302-01 - Twist Drill 251 73.000

251 73.000

Артикул: 9002510730000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

DAMPF ANGELASSEN

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

73 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

MKG00602085

FamilyProducts

HSS SPIRALB,VERST.MK 73,000 DIN 346RN MK

FHA Flute helix angle

37 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

315 mm

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSS

GRDSYC Grind style code

HAND Cutting direction

R - Right

ID Technical product number

9002510730000

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

255 mm

LF Functional length

277 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

MKG Morse taper

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0060

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

MKG00602085

LPR Protruding length

299 mm

LS Shank length

218 mm

LU Usable length

184 mm

Name Identifying order number

251 73.000

NOF Flute count

OAL Overall length

509 mm

PL Point length

22 mm

SIG Point angle 1st step

118 Degree

STDNO Standard

DIN346

Working process

BVB - Drilling

WT Weight of item

12.897 kg
