Главная Каталог продукции Toolunited 12 302-01 - Twist Drill 247 23.000

247 23.000

Артикул: 9002470230000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

OHNE

COMPC Company code

GG - Gühring

CRCLDIN Chip removal class

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

23 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

MKG00202085

FamilyProducts

HSS SPIRALBOHRER 23,000 DIN 345RW MK

FHA Flute helix angle

38 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

90 mm

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSS

GRDSYC Grind style code

HAND Cutting direction

R - Right

ID Technical product number

9002470230000

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

155 mm

LF Functional length

172.6 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

MKG Morse taper

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0020

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

MKG00202085

LPR Protruding length

178 mm

LS Shank length

80 mm

LU Usable length

133 mm

Name Identifying order number

247 23.000

NOF Flute count

OAL Overall length

253 mm

PL Point length

5.4 mm

SIG Point angle 1st step

130 Degree

STDNO Standard

DIN345

Working process

BVB - Drilling

WT Weight of item

0.408 kg
