Главная Каталог продукции Toolunited 12 302-01 - Twist Drill 2463 4.300

2463 4.300

Артикул: 9024630043000

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

NANOFIRE

COMPC Company code

GG - Gühring

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

4.3 mm

DCONMSLD Shank diameter lower limit

-0.008 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2021

DIN

ZYL00430105

FamilyProducts

VHM NANOFIRE SPIBO EXTRA KURZ DIN 6539RN

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

23.4 mm

GRD2ND Standard designation of the grade 2nd application

VHM

GRDMFG Grade manufacturers designation

VHM

GRDPRIO Standard designation of the grade main application

HC-K/P

HAND Cutting direction

R - Right

ID Technical product number

9024630043000

Interface codes

J6 / J61

ISO

ZYL00430105h$06

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

24 mm

LF Functional length

56.7 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0043

LOC-03 DCONMS Diameter

4.3 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03 ISO

ZYL00430105h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00430105

LPR Protruding length

29 mm

LS Shank length

34 mm

LU Usable length

18 mm

Name Identifying order number

2463 4.300

NOF Flute count

OAL Overall length

58 mm

PL Point length

1.3 mm

SIG Point angle 1st step

118 Degree

STDNO Standard

DIN6539

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling

WT Weight of item

0.01 kg
